Original Deep Sea DSE7320 MKII Automatic Start Control Module for Generator Systems

Description

Original Auto Start Control Module DSE7320 DSE7320 MKII
Application：Deep Sea

Interchange part number:DSE7320 DSE7320 MKII

Description:

Auto Start Control Module

Condition: New

PLEASE NOTE: Genuine/Original parts do not provide return or exchange service.

Specifications:
1.Engine Parameters: Speed, oil pressure, water temperature, battery voltage, oil level %, operating hours, start times and charging motor voltage
2.Generator Parameters: Frequency, three-phase voltage (L-L, L-N) and three-phase current
3.Power Parameters: KVA, KW, PF, KVAR, KWh, KVAH and KVAR
4.Mains Electricity Parameters: Frequency, three-phase voltage (L-L, L-N)
5.Alarm Level: Pre-alarm, electrical trip and shut down
6.Speed Sensor Frequency Range: 1Hz-10KHz
7.Speed Sensor Voltage Range: ±0.5V (start)~ 70V
8.Fuel Relay Output A: 15 Amp DC output
9.Start Output B:15 Amp DC output
10.Relay Output C and D: 8Amp 250V passive contact output
11.User-defined output E, F, G and H: 2Amp DC output
12.Opening Size for Mounting: 22*16cm/8.7*6.3in
Function:
1.AMF + ATS + communication + extension functions;
2.Manual control fuel pump;Manual control engine speed (engine has electrically operated injector);Preset running time (units need to start on a regular intervals, to run maintenance operation);
3.Preset maintenance cycle function (after engine running 250 hours, need to change oil filter, fuel filter, air filter, etc.);
4.Engine, generator monitoring and protection functions;
5.Engine speed, engine oil pressure, engine water temperature, battery voltage, generator voltage;
6.Generator current, engine frequency;Has PLC logical function (maximum supports 50 steps);Sleep mode to save power;
7.Hierarchical load rejection – loading/hierarchical virtual load (load box);250 event log (with date and time).  Package Includes:1 x Controller                               4 x Screws
